Pixel Pitch: P4mm, P4x8mm, P6mm, P8mm, P10mm,P16mm
Cabinet Size: 800x240x3mm, 1000x240x3mm, or customized
1. Superb transparency with PET film, more than 85% transparency rate
2. Extremely thin body with only 3-5mm thickness, less than 3.5kg/sqm
3. Flexible in LED screen shape, suitable for flat and curve screen
4. Wide viewing angle of 140 degree H/V directions
5. Fast installation, directly stick to the glass windows
6. Above 3,000nits brightness, vivid color performance
The TF Series Transparent LED Film redefines spatial visual communication through its Superb Transparency, a defining trait that aligns it with top-tier Transparent LED Display offerings. A core advantage of this film (as highlighted in its design): when attached to surfaces (like glass) and turned off, it clearly reflects the object behind it — preserving a wide-open, unobstructed view that keeps spaces feeling airy and uncluttered.
| Transparent LED Film Specification | ||||||
| Product Model | TF-4 | TF-4*8 | TF-6 | TF-8 | TF-10 | TF-16 |
| Pixel Pitch | 4mm*4mm (HxW) | 4mm*8mm (HxW) | 6mm*6mm (HxW) | 8mm*8mm (HxW) | 10mm*10mm (HxW) | 16mm*16mm (HxW) |
| Pixel Density (Dots/㎡) | 62,500 | 31,250 | 27,556 | 15,625 | 10,000 | 3,844 |
| LED Type | SMD1010 (LED&IC packed in 1) | SMD1010 (LED&IC packed in 1) | SMD2121 (LED&IC packed in 1) | SMD2121 (LED&IC packed in 1) | SMD2121 (LED&IC packed in 1) | SMD2121 (LED&IC packed in 1) |
| Pixel Configuration | 1R1G1B | 1R1G1B | 1R1G1B | 1R1G1B | 1R1G1B | 1R1G1B |
| Module Size | 800mm*240mm | 1000mm*240mm | 1000mm*240mm | 1000mm*240mm | 1000mm*240mm | 1000mm*240mm |
| Module Resolution (Pixels) | 200*60 | 250*30 | 166*40 | 125*30 | 100*24 | 62*15 |
| Transparency Rate | ≥85% | ≥85% | ≥85% | ≥85% | ≥90% | ≥90% |
| Cabinet Cable Connection | Internal connection | Internal connection | Internal connection | Internal connection | Internal connection | Internal connection |
| Weight | ≤ 3.5KG/m2 | ≤ 3.5KG/m2 | ≤ 3.5KG/m2 | ≤ 3.5KG/m2 | ≤ 3.5KG/m2 | ≤ 3.5KG/m2 |
| Brightness | ≥3000cd/㎡ | ≥3000cd/㎡ | ≥3000cd/㎡ | ≥3500cd/㎡ | ≥3500cd/㎡ | ≥3500cd/㎡ |
| Peak Power Consumption | 600 W/㎡ | 600 W/㎡ | 600 W/㎡ | 600 W/㎡ | 600 W/㎡ | 600 W/㎡ |
| Average Power Consumption | ≈ 200 W/㎡ | ≈ 200 W/㎡ | ≈ 200 W/㎡ | ≈ 200 W/㎡ | ≈ 200 W/㎡ | ≈ 200 W/㎡ |
| Refresh Rate | ≥3840s | ≥3840s | ≥3840s | ≥3840s | ≥3840s | ≥3840s |
| Gray Scale | 16Bit | 16Bit | 16Bit | 16Bit | 16Bit | 16Bit |
| Brightness Control Level | 0-255 | 0-255 | 0-255 | 0-255 | 0-255 | 0-255 |
| Color Temperature | 3200K-8500K (adjustable) | 3200K-8500K (adjustable) | 3200K-8500K (adjustable) | 3200K-8500K (adjustable) | 3200K-8500K (adjustable) | 3200K-8500K (adjustable) |
| Frame Rate | ≥60Hz | ≥60Hz | ≥60Hz | ≥60Hz | ≥60Hz | ≥60Hz |
| Viewing Angle | H140° / V140° | H140° / V140° | H140° / V140° | H140° / V140° | H140° / V140° | H140° / V140° |
| Input Signal | DVI VGA, composite video | DVI VGA, composite video | DVI VGA, composite video | DVI VGA, composite video | DVI VGA, composite video | DVI VGA, composite video |
| Control Method | Synchronous controller (computer control screen) or asynchronous controller (WiFi connection mobile phone APP control screen, USB flash drive control screen) | Synchronous controller (computer control screen) or asynchronous controller (WiFi connection mobile phone APP control screen, USB flash drive control screen) | Synchronous controller (computer control screen) or asynchronous controller (WiFi connection mobile phone APP control screen, USB flash drive control screen) | Synchronous controller (computer control screen) or asynchronous controller (WiFi connection mobile phone APP control screen, USB flash drive control screen) | Synchronous controller (computer control screen) or asynchronous controller (WiFi connection mobile phone APP control screen, USB flash drive control screen) | Synchronous controller (computer control screen) or asynchronous controller (WiFi connection mobile phone APP control screen, USB flash drive control screen) |
| Protection Grade | IP30 | IP30 | IP30 | IP30 | IP30 | IP30 |
| Power Input | AC 110-220V ± 10%, 50-60Hz | AC 110-220V ± 10%, 50-60Hz | AC 110-220V ± 10%, 50-60Hz | AC 110-220V ± 10%, 50-60Hz | AC 110-220V ± 10%, 50-60Hz | AC 110-220V ± 10%, 50-60Hz |
| Working Temperature | -20~50 ℃ | -20~50 ℃ | -20~50 ℃ | -20~50 ℃ | -20~50 ℃ | -20~50 ℃ |
| LED Lift Span | 100000 hours | 100000 hours | 100000 hours | 100000 hours | 100000 hours | 100000 hours |
